3D laser tube and pipe bevel cutting machine

3D bevel pipe cutter is a professional laser pipe cutting machine, it can cut various shapes of pipes such as H steel, angel steel and C steel to achieve bevel cutting, and it is a small and medium power and small size fiber laser cutting machine. It has a sealed laser head structure, which is not affected by dust, accurate and convenient focus adjustment, and easy-to-replace protective lenses. It is a practical laser pipe cutting machine developed according to the needs of bulk pipe processing users.

TK 3d laser bevel cutting machine ADVANTAGES

1. ±45° flexible cutting

Realizes bevel cutting of workpieces in the range of 0°-45°.

2. Automatic unloading to save labor costs

Automatic unloading, stable and safe, no need for manual unloading.

3. Four pneumatic chucks

Adaptive adjustment of clamping force is realized by sensing the clamping state of the jaws and pipe size data.

TK 3d laser bevel cutting machine

APPLICATIONS

3D laser bevel cutting machine is suitable for all kinds of tube shapes: round tube, square tube, rectangular tube, oval tube, angle steel, channel steel, H-beam, and I-beam. etc. It is widely used in petrochemical, aerospace, automobile manufacturing, construction, decoration and other industries.

TK 3d laser bevel cutting machine

SPECIFICATIONS

Model

TK6220/TK9220

MAX. TUBE LENGTH

6.5m/9.2m

MAX. TUBE WEIGHT

300kg 16kg/m

LASER POWER

1kW – 4kW

CLAMPING RANGE

Φ20-Φ220mm
□20 – □150mm

TUBE SHAPE

Round/square/rectangular

CHUCK

 4 pneumatic chucks

MAX. CHUCK ROTATING SPEED

130r/min

TK 3d laser bevel cutting machine

PREMIUM COMPONENTS

3d-laser-bevel-cutting-machine

Automatic unloading device, high efficiency, saving labor costs

3d-laser-bevel-cutting-machine

It can realize X/Y/Z-axis cutting and improve the efficiency of cutting dense and small graphics.

3d laser bevel cutting machine

The chucks are fast and dynamic for easy and stable clamping of heavy tubing.

Q&A

What is your after-sale service?

After-sale Service

DXtechEurope has a complete sales and after-sales service system to provide a full range of laser application solutions for customers in different industries around the world.

DXTECHEUROPE provides 24 month warranty for the whole fiber laser machine.
1. Within the warranty period, under normal use and maintenance, we will change the broken parts for free. (laser source only repaired but not replaced. )
2. Out of the warranty period, you will get the spare part at the cost price. Our Engineers still give you the best technical service within 24 hours.
3. You will also get technical support and service all your lifetime.

How thick the laser cutting machine can cut the material?

Different power levels of fiber laser cutting machines can cut materials with different thicknesses.

Generally, low-power laser cutting machines can cut thin materials, such as metal plates up to 6 mm thick and non-metallic materials such as wood or acrylic up to about 20 mm thick.

Medium-power laser cutting machines can cut medium-thick materials, such as metal plates up to 12 mm thick and non-metallic materials such as wood or acrylic up to about 30 mm thick.

High-power laser cutting machines can cut thick materials, such as metal plates up to 25 mm thick and non-metallic materials such as wood or acrylic up to 40 mm thick or more.

However, it should be noted that laser cutting machines can cut larger material thicknesses with enough laser power and the proper lens, but this depends on the equipment’s manufacturing and related safety requirements.

What are the applications of laser cutting machine?

Fiber laser cutting machine is widely used in the following fields:

1. Metal products processing: including metal plate processing, metal pipe processing, mechanical parts processing, etc.

2. Electronic products manufacturing: mainly used for circuit board cutting, device cutting and fine parts processing, etc.

3. Mold manufacturing: mainly used for mold steel plate opening, mold parts processing, mold trimming, etc.

4. Construction decoration: mainly used for metal decoration material making and customized construction components.

5. Precision parts manufacturing: mainly used for the manufacturing of precision parts such as watches, glasses, jewelry and auto parts.

6. Food processing: mainly used for food cutting and packaging, etc. For example, for laser-cutting sweets, it can create various shapes of desserts and can be personalized according to customers’ requirements.

7. medical devices: mainly used for processing and manufacturing of medical devices, such as scalpels, syringes, etc.

In general, fiber laser cutting machine has become an indispensable cutting tool in modern manufacturing industry, which is widely used in various fields of production and processing.

SPECIFICATIONS

Model

TK6220/TK9220

Max. tube length

6.5m/9.2m

Max. tube weight

300kg 16kg/m

Tube shape

Round/square/rectangular

Laser power

1kW – 4kW

Chuck

 4 pneumatic chucks

Max. chuck rotating speed

130r/min

Clamping range

Φ20-Φ220mm
□20 – □150mm

Positioning accuracy

±0.03mm
